42.7 Voltage Range Linear Voice Coil High Precision Linear Coil Actuator
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | SUPT MOTION |
| Certification | ISO9001 |
| Model Number | VCAH0253-0120-00A |
| Minimum Order Quantity | 3PCS |
| Price | $110-$135 |
| Packaging Details | Customized packaging etc. |
| Delivery Time | 1-5pcs ,5 days . >20pcs ,To be negotiated |
| Payment Terms | T/T |
| Supply Ability | To be negotiated |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Force Output | High | Positioning Accuracy | High |
|---|---|---|---|
| Voltage Range | 42.7 | Product Type | Linear Voice Coil Motor |
| Repeatability | High | Current Range | 4.2 |
| Linearity | High | ||
| Highlight | 42.7 Voltage Range Linear Voice Coil,Linear Coil Actuator 42.7 Voltage Range,High Precision Linear Coil Actuator ISO9001 |
||
Product Description
Linear Voice Coil VCAH0253-0120-00A Low Noise Level High-Precision
Product Description:
The Linear Voice Coil Motor is a precision linear voice coil device that features high positioning accuracy, low power consumption, low noise and a stroke length of 12. With an operating current range of 4.2A, it is a popular choice for applications requiring precise linear motion.
The Linear Voice Coil Motor is a reliable, efficient device that is ideal for applications requiring precise linear motion. Its high positioning accuracy and low power consumption make it ideal for any application requiring precision and efficiency.
Built-in motion axis and precision linear bearings. The motion axis is made of lightweight, highly rigid and wear-resistant premium materials.
Widely used in semiconductor, precision testing and inspection, valve flow control, etc.
Application areas for the VCAH series of actuators include valve actuators, Z-axis pick and place, small precision positive displacement metering pumps, and vibrators and active vibration damping systems. Markets include medical semiconductor, aerospace and automotive.
Features:
- Linear Voice Coil Motor
- Speed Range: High Speed
- Positioning Accuracy: High
- Repeatability: High
- Linearity: High
- Noise Level: Low
Technical Parameters:
| Parameter | Value |
|---|---|
| Model Number | VCAH0253-0120-00A |
| Product Type | Linear Voice Coil Motor |
| Force Output | High |
| Repeatability | High |
| Speed Range | High Speed |
| Noise Level | Low |
| Power Consumption | Low |
| Linearity | High |
| Resolution | High |
| Stroke Length | 12 |
| Product Model | Peak Force (N) |
Continuous Force at 25℃(N) |
Total Stroke (mm) |
Max Voltage (V) |
Back EMF Constant (V/m/s) |
Stator Diameter (mm) | The Length (mm) |
Shaft end thread (mm) |
| VCAH0253-0120-00A | 253 | 46.5 | 12 | 42.7 | 16 | 53.95 | 109 | M5(Inner) |
| VCAH0011-0070-00A | 11 | 3.6 | 7 | 26.2 | 4.9 | 31.5 | 38.9 | M3(Outer) |
| VCAH0013-0070-00A | 13 | 4.2 | 7 | 26.6 | 5.7 | 29 | 40.5 | M3(Outer) |
| VCAH0030-0100-00A | 30 | 7.2 | 10 | 24.9 | 5.2 | 37 | 47 | M3(Outer) |
| VCAH0040-0075-00A | 40 | 12.3 | 7.5 | 16.8 | 6.9 | 36 | 50 | ∮3 |
| VCAH0040-0240-00A | 40 | 6 | 24 | 44.5 | 8 | 41 | 83 | M3(Inner) |
| VCAH0065-0140-00A | 65 | 24.6 | 14 | 27.6 | 16 | 44 | 75 | M3(Inner) |
| VCAH0230-0110-00A | 230 | 100 | 11 | 34.2 | 37 | 71 | 117 | ∮10 |
Applications:
SUPT MOTION's Linear Voice Coil product (VCAH Series) is a powerful motor solution designed for a variety of linear motion applications in Jiangsu, China. It features a 4.2 current range, high resolution, high speed and 12 stroke lengths, and high positioning accuracy. The Linear Voice Coil product is the best choice for those looking for an efficient, reliable and cost-effective linear motion solution.
It is widely used in semiconductors, precision test and inspection, marine, automotive, e-bikes, drones, 3D printing, microscopes, robotics, medical ventilators, optical engineering, and more.
