High Accuracy Vibrating Sieve Motor High Acceleration Vcm Vibratory Motor
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | SUPT |
| Certification | ce,ISO9001 |
| Model Number | VCAZ0010-0020 |
| Minimum Order Quantity | ≥1 |
| Price | $85.00/pieces >=1 pieces |
| Packaging Details | carton & wooden box vibration motor |
| Delivery Time | 1-5 products 5-7 days shipment, samples 3-5 days, bulk to be negotiated |
| Payment Terms | T/T |
| Supply Ability | 3000 Piece/Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Warranty | 3months-1year | Usage | BOAT, Car, Electric Bicycle, 3D Printing,Microscope,Robot,Medical Ventilators,Optical Project |
|---|---|---|---|
| Type | Micro Motor | Torque | Requests |
| Construction | Permanent Magnet | Commutation | Brush |
| Protect Feature | Totally Enclosed | Speed(RPM) | 50 |
| Continuous Current(A) | 1.52 | Efficiency | IE 1 |
| Peak Force(N) | 10.2 | Maximum Travel(mm) | 2.0 |
| Vibration Motor(V) | 25.6 | Actuator Weight (g) | 68 |
| Continuous Force(N) | 4.72 | Port | Shanghai Vibration Motor |
| Highlight | High Promotion Vibrating Sieve Motor,Vibrating Sieve Motor High Acceleration Vcm,High Acceleration Vcm Vibratory Motor |
||
Product Description
High Promotion Vibration Sieve Machine Vibration Motor High Acceleration
Product Description
Vibration motors are very popular in many applications, especially in scenarios where vibration or vibration effects are required. The following are some common application areas, among which vibration motors are more popular:
1. Mobile devices: Vibration motors are widely used in smartphones, tablets, and wearable devices to provide tactile feedback, notifications, and reminders.
2. Medical Equipment: In medical devices, vibration motors can be used for applications such as physical therapy, massage equipment, and acoustic cleaners, helping to promote health and comfort.
3. Industrial automation: In automation systems, vibration motors are used for operations such as conveying, screening, sorting, and compaction, improving production efficiency.
4. Car: In cars, vibration motors can be used to provide tactile feedback to the driver, such as in vehicle warnings and navigation prompts.
5. Aerospace: In the field of aviation and aerospace, vibration motors can be used to simulate the vibration and vibration conditions of aircraft for testing and simulation.
6. Tools and Instruments: Among various tools and instruments, vibration motors can be used for vibration and vibration testing, calibration, etc.
Applications:
The product described in this paper is a vibration motor, its model is VCAZ0010-0020, its origin is Jiangsu, China, with short response time, high vibration frequency, good induction, good stability, high accuracy and other characteristics, the flexible feeding mechanism of voice coil motor solves the feeding problem which can not be solved by the traditional vibrating disc. The flexible vibration plate of voice coil motor adopts special drive and control technology, which can realize the forward and reverse motion turning, dispersion and aggregation of parts. Also can adjust the back light source, can complete vibration feeding, vision system automatic control and machine pick-up system automatic control. Our vibrating motor design provides reliable and long-lasting performance. They are also easy to install and maintain, making them ideal for any application. We offer a variety of sizes and configurations to make our vibrating motors the perfect solution for any application.
Technical Parameters:
| Winding constant |
VALUE |
UNIT |
| DC resistance | 10.2 | Ω |
| Voltage @ Fp |
25.9 | V |
| Current @ Fp |
2.6 | A |
| Inductance |
1.3 | mH |
| Peak force |
20.5 | N |
| Con force |
8.9 | N |
| Actuator constant |
2.55 | Ka |
| Power @ Fp |
65.3 | W |
| Total stroke |
3 | mm |
| Max winding temp |
150 | ºC |
| Actuator weight |
110 | g |
Our Services
Technical indicators & specifications can be customized
Satisfactory after-sales service
Company Information
FAQ
stator:
1.Travel: effective travel, used to calculate the the total travel of value force.
2.The direction of movement: horizontal or vertical installation 90 degree.
3.Load force: constant in the reverse direction of force on the motor, such as springs, etc.
4.Load weight: the total quality part of movement, including the quality slider
5.Movement Type: 1.point to point movement; 2.the reciprocation of the rule (e.g. scanning).
6.Velocity curve: 1.a trapezoidal speed curve; 2.triangular speed curve; 3.sine speed curve.
